Product Overview
G005159
11
10
13
8
7
14
11
3
5
12
4
6
12
3
9
2
1
Figure 5
1. Mount plate 5. Fuel tank 9. Auxiliary hydraulic couplers 13. Air cleaner
2. Tilt cylinder 6. Wheel 10. Control panel 14. Counterweight
3. Loader arms 7. Operator platform 11. Lift points
4. Lift cylinder
8. Engine
12. Handles
Controls
Become familiar with all the controls ( Figure 6 )
before y ou star t the engine and operate the traction
unit.
G005160
631524
789
Figure 6
1. Traction control levers 6. Throttle lever
2. Attachment tilt lever 7. Choke lever
3. Loader arm lever 8. Key switch
4. Auxiliary hydraulics lever
9. Hour meter
5. Speed selector lever
Key Switch
T he k ey switc h, used to star t and stop the engine ,
has three positions: off , r un, and star t.
T o star t the engine , rotate the k ey to the star t
position. R elease the k ey when engine star ts and it
will mo v e automatically to the r un position.
T o stop the engine , rotate the k ey to the off
position.
Throttle Lever
Mo v e the control forw ard to increase the engine
speed and rearw ard to decrease speed.
Choke Lever
Before star ting a cold engine , mo v e the c hok e
lev er forw ard. After the engine star ts , regulate the
c hok e to k ee p the engine r unning smoothly . As
soon as possible , mo v e the c hok e lev er all the w a y
rearw ard.
Note: A w ar m engine requires little or no
c hoking .
Traction Control Levers
T o mo v e forw ard, mo v e the traction control lev ers
forw ard. T o mo v e rearw ard, mo v e the traction
control lev ers rearw ard.
13
