Greensmaster 3100
Dual Point Adjust Cutting units
Page 10 - 7
Set Up and Adjustments
Characteristics
CAUTION
Never install or work on the cutting units or lift
arms with the engine running. Always stop en-
gine and remove key first.
The dual knob bedknife–to–reel adjustment system in-
corporated in this cutting unit simplifies the adjustment
procedure needed to deliver optimum mowing perfor-
mance. The precise adjustment possible with this de-
sign gives the necessary control to provide a continual
self–sharpening action. This feature maintains sharp
cutting edges, assures good quality of cut, and greatly
reduces the need for routine backlapping.
In addition, the rear roller positioning system allows for
two height-of-cut ranges.
If a cutting unit is determined to be out of adjustment,
complete the following procedures in the specified order
to adjust the cutting unit properly.
1. Adjust the bedknife parallel to the reel.
2. Determine desired height of cut range and install
rear roller mounting shim accordingly.
3. Adjust the height-of-cut.
4. Adjust the cut-off bar.
See Cutting Unit Operator’s Manual for adjustment pro-
cedures for the cutting units on the Greensmaster 3150.
Rev. D
