Groundsmaster 4500 --D/4700--DPage 7 -- 6Chassis
Traction Pedal
1. Washer head screw (2 used)
2. Reverse pedal pad
3. Pedal assembly
4. Spring pin
5. Forward pedal pad
6. Accelerator pedal
7. Cap screw
8. Flat washer
9. Jam nut
10. Rod end bearing
11. Slotted roll pin
12. Cap screw (4 used)
13. Flange bearing mount
14. Flange nut (2 used)
15. Washer head screw (2 used)
16. Standoff spacer (2 used)
17. Roll pin
18. Pivot hub
19. Spring shaft
20. Plastic plug
21. Roll pin
22. Spring bracket
23. Spring retainer
24. Compression spring
25. Flat washer
26. Sensor cover plate
27. Traction pivot shaft
28. Spring pin
29. Position sensor
30. Hub
31. Flange nut
32. Capture plate
33. Cap screw (2 used)
Figure 5
FRONT
RIGHT
7
8
9
10
11
12
13
18
19
21
22
23
24
25
29
32
33
16
26
17
15
30
31
2
4
6
3
5
1
14
20
27
28
