Groundsmaster 4500 --D/4700--DCutting Decks Page 8 -- 6

Adjustments

CAUTION

Never install or work on the cutting decks or lift

arms with the engine running. Always stop en -

gine and remove key from ignition switch first.

See the Cutting Deck Operator’s Manual for adjustment

procedures for cutting decks on the G roundsmaster

4500--D and Groundsmaster 4700--D.

Blade Stopping Time

Thebladesofthecuttingdecksaretocometoacom-

plete stop in approximately five (5) seconds after the

PTO is disengaged.

NOTE: Make sure the decks are lowered onto a c lean

section of turf or hard surface to avoid dust a nd debris.

To verify this stopping time, have a second person stand

back from the machine at least twenty (20) feet and

watch the blade on one of the cutting decks. Have the

machine operator disengage the PTO and record the

timeittakesforthecuttingdeckbladetocometoacom-

plete stop. If this time is greater than seven (7) seconds,

the deck control manifold braking valve (RV) may need

adjustment.
