Groundsmaster 4500 --D/4700--DCutting Decks Page 8 -- 12
Rear Roller
1. Deck frame
2. Rear roller assembly
3. Grease fitting
4. Roller shaft screw
5. Roller mount
6. Flange head screw
7. Skid bracket
8. Cap screw
Figure 10
8
5
4
1
7
6
3
2
FRONT
RIGHT
29 to 35 ft--lb
(40 to 47 N--m)
29 to 35 ft--lb
(40to47N--m)
