RaisingtheRollBar
RaisetherollbarasshowninFigure11.
g031636
g031631
Figure12
Important:Alwaysusetheseatbeltwhenthe
rollbarisintheraisedandlockedposition.Do
notusetheseatbeltwhentherollbarisinthe
loweredposition.
AdjustingtheHeightofCut
Youcanadjusttheheightofcutfrom2.5to15.8cm
(1to6inches)in6mm(1/4inch)incrementsby
relocatingthestoppinintodifferentholelocations.
1.Withtheenginerunning,pushthedeck-lift
switchupuntilthemowerdeckisfullyraisedand
releasetheswitchimmediately(Figure24).
2.Rotatethestoppinuntiltherollpininitlinesup
withtheslotsintheholesintheheight-of-cut
bracketandremoveit(Figure13).
3.Selectaholeintheheight-of-cutbracket
correspondingtotheheightofcutdesired,insert
thepin,androtateitdowntolockitinplace
(Figure13).
Note:Thereare4rowsofholepositions
(Figure13).Thetoprowgivesyoutheheightof
cutlistedabovethepin.Thesecondrowdown
givesyoutheheightlistedplus6mm(1/4inch).
Thethirdrowdowngivesyoutheheightlisted
plus12mm(1/2inch).Thebottomrowgivesyou
theheightlistedplus18mm(3/4inch).Forthe
15.8cm(6inch)position,thereisonly1hole,
locatedinthesecondrow.Thisdoesnotadd
6mm(1/4inch)tothe15.8cm(6inch)position.
g020870
Figure13
1.Stoppin2.Height-of-cutstop
4.Adjusttheanti-scalprollersandskidsas
required.
