Toro Groundsmaster 7210 Series User Manual

AdjustingtheTraction
DriveforNeutral
Makethisadjustmentwiththedrivewheelsturning.
DANGER
Mechanicalorhydraulicjacksmayfailto
supportthemachineandcauseaserious
injury.
•Usejackstandswhensupportingthe
machine.
•Donotusehydraulicjacks.
WARNING
Theenginemustberunningtoperformthis
adjustment.Contactwithmovingpartsorhot
surfacesmaycausepersonalinjury.
Keephands,feet,face,clothing,andother
bodypartsawayfromrotatingparts,mufer,
andotherhotsurfaces.
1.Raisetheframeontostablejackstandssothat
thedrivewheelscanrotatefreely.
2.Slidetheseatforward,unlatchit,andswingitup
andforward.
3.Disconnecttheelectricalconnectorfromthe
seatsafetyswitch.
4.Temporarilyinstallajumperwireacrossthe
terminalsinthewireharnessconnector.
5.Starttheengine,ensurethatthethrottleleveris
midwaybetweentheFASTandSLOWpositions,
andreleasetheparkingbrake.
Note:Themotion-controlleversmustbein
theNEUTRAL-LOCKpositionwhileyoumakeany
adjustments.
6.Adjustthepumprodlengthononesideby
rotatingthehexshaft,intheappropriate
direction,untilthecorrespondingwheelisstillor
slightlycreepinginreverse(Figure87).
g004488
Figure87
1.Rightpumprod5.Jamnut
2.Leftpumprod6.Hexshaft
3.Balljoint7.Balljoint
4.Bolt
7.Movethemotion-controlleverforwardand
reverse,thenbacktoneutral.
Note:Thewheelmuststopturningorslightly
creepinreverse.
8.MovethethrottlelevertotheFASTposition.
Note:Makesurethatthewheelremains
stoppedorslightlycreepsinreverse;adjustit
ifnecessary.
9.Repeatsteps6through8fortheothersideof
themachine.
10.Tightenthejamnutsattheballjoints(Figure85).
11.MovethethrottlelevertotheSLOWpositionand
shutofftheengine.
12.Removethejumperwirefromthewireharness
connectorandplugtheconnectorintotheseat
switch.
58
