Toro Groundsmaster 7210 Series User Manual

WARNING
Theelectricalsystemdoesnotperform
propersafetyshutoffwiththejumper
wireinstalled.
•Removethejumperwirefromthe
wireharnessconnectorandplugthe
connectorintotheseatswitchwhen
youcompleteadjustment.
•Neveroperatethemachinewiththe
jumperinstalledandtheseatswitch
bypassed.
13.Lowertheseatintoposition.
14.Removethejackstands.
AdjustingtheMaximum
GroundSpeed
1.DisengagethePTO,movethemotion-control
leverstotheNEUTRAL-LOCKposition,and
engagetheparkingbrake.
2.MovethethrottlelevertotheSLOWposition,
shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Removetheboltssecuringthefrontpaneland
removethepanel(Figure88).
g020875
Figure88
1.Bolt
2.Controlpanel
4.Loosenthejamnutonthestopboltforacontrol
lever(Figure89).
g004766
Figure89
1.Stopbolt
3.Jamnut
2.Controllever4.1.5mm(0.060inch)
5.Threadthestopboltallthewayin(awayfrom
thecontrollever).
6.Pushthecontrolleverallthewayforwarduntilit
stopsandholditthere.
7.Threadthestopboltout(towardthecontrol
lever)untilthereisagapof1.5mm(0.060
inch)betweentheheadofthestopboltandthe
controllever.
Note:Ifyouwanttoreducethemaximum
machinespeed,backeachstopboltoutan
equalamounttowardthecontrolleveruntilyou
reachthedesiredmaximumspeed.Youmay
needtotestyouradjustmentseveraltimes.
8.Tightenthejamnuttosecurethestopboltin
place.
9.Repeatsteps4through8fortheothercontrol
lever.
10.Installthefrontpanel.
11.Ensurethatthemachinedrivesstraightand
doesnotturnwhenbothcontrolleversare
pushedallthewayforward.
Note:Ifthemachineturns,thestopboltsare
notevenlysetandyouneedtoadjustthem
further.
59
