Toro Groundsmaster 7210 Series User Manual

ControlsSystem
Maintenance
AdjustingtheControl-Lever
Neutral-InterlockSwitch
1.Stopthemachine,movethemotion-control
leverstotheNEUTRAL-LOCKposition,engagethe
parkingbrake,andremovetheignitionkey.
2.Removetheboltssecuringthefrontpaneland
removethepanel(Figure82).
g020875
Figure82
1.Bolt
2.Controlpanel
3.Loosenthe2screwssecuringtheinterlock
switch(Figure83).
g004763
Figure83
1.Controllever3.Screw
2.Neutral-interlockswitch
4.0.4to1mm(0.015to
0.045inch)
4.Holdingthecontrolleveragainsttheframe,
movetheswitchtowardtheleveruntilthe
distancebetweentheleverandswitchbodyis
0.4to1mm(0.015to0.045inch)asshownin
Figure83.
5.Securetheswitch.
6.Repeatsteps3to5fortheotherlever.
7.Installthefrontpanel.
AdjustingtheControl-Lever
NeutralReturn
Ifthemotion-controlleversdonotalignwiththe
neutralslotswhenreleasedfromtheREVERSE
position,adjustmentisrequired.Adjusteachlever,
spring,androdseparately.
1.DisengagethePTO,movethecontrolleverto
theNEUTRAL-LOCKposition,andengagethe
parkingbrake.
2.MovethethrottlelevertotheSLOWposition,
shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Removetheboltssecuringthefrontpaneland
removethepanel(Figure84).
56

Toro Groundsmaster 7210 Series Specifications

General

Drive System	2WD
Number of Blades	3
Horsepower	24.8 hp (18.5 kW)
Transmission	Hydrostatic
Cutting Height	1-5 in (2.5-12.7 cm)
Engine Displacement	1123 cc
