Toro Super Recycler 20383 User Manual

EngagingtheBlade
Whenyoustartyourengine,thebladedoesnotturn.
Youmustengagethebladetomow.
1.Pullthecontrol-barlockback(Figure20).
g003123
Figure20
2.Pulltheblade-controlbartothehandle(Figure
21).
g003124
Figure21
3.Holdtheblade-controlbaragainstthehandle
(Figure22).
g003125
Figure22
DisengagingtheBlade
Releasetheblade-controlbar(Figure23).
g003126
Figure23
Important:Whenyoureleasetheblade-control
bar,thebladeshouldstopwithin3seconds.Ifit
doesnotstopproperly,stopusingyourmachine
immediatelyandcontactanAuthorizedService
Dealer.
Checkingthe
Blade-Brake-Clutch
Operation
Checkthecontrolbarbeforeeachusetoensurethat
theblade-brake-clutchsystemisoperatingproperly.
UsingtheGrassBag
ServiceInterval:Beforeeachuseordaily
Youcanusethegrassbagtoperformanadditional
testtochecktheblade-brakeclutch.
1.Installtheemptygrassbagonthemachine.
2.Starttheengine.
3.Engagetheblade.
Note:Thebagshouldbegintoinate,indicating
thatthebladeisengagedandrotating.
4.Releasetheblade-controlbar.
Note:Ifthebagdoesnotimmediatelydeate,
thebladeisstillrotating.Theblade-brakeclutch
maybedeterioratingand,ifignored,could
resultinanunsafeoperatingcondition.Have
themachineinspectedandservicedbyan
AuthorizedServiceDealer.
5.Shutofftheengineandwaitforallmovingparts
tostop.
NotUsingtheGrassBag
1.Movethemachineontoapavedsurfaceina
non-windyarea.
14

Toro Super Recycler 20383 Specifications

General

Brand	Toro
Model	Super Recycler 20383
Category	Lawn Mower
Type	Walk-Behind
Engine	Briggs & Stratton
Engine Displacement	163 cc
Drive System	Personal Pace Rear-Wheel Drive
Deck Material	Cast Aluminum
Mulching Capability	Yes
Bagging Capability	Yes
Side Discharge	Yes
Starting System	Recoil
Cutting Height Adjustment	4-point
Fuel Capacity	0.25 gallons
Starter Type	Pull Cord
Cutting Width	22 inches
