Toro Super Recycler 20383 User Manual

fueltanktorundrythroughnormalusage.If
youmusttipthemachinepriortorunning
outoffuel,useahandfuelpumptoremove
thefuel.Alwaystipthemachineontoits
side,withthedipstickdown.
ServicingtheAirFilter
ServiceInterval:Yearly
1.Pressdownonthelatchtabsontopofthe
air-ltercover(Figure39).
g011722
Figure39
1.Latchtabs
3.Foampre-lter
2.Paperairlter
2.Openthecover.
3.Removethepaperairlterandthefoam
pre-lter(Figure39).
4.Inspectthefoampre-lter,andreplaceitifitis
damagedorexcessivelydirty.
5.Inspectthepaperairlter.
•Iftheairlterisdamagedoriswetwithoil
orfuel,replaceit.
•Iftheairlterisdirty,tapitonahardsurface
severaltimesorblowcompressedairless
than207kPa(30psi)throughthesideofthe
lterthatfacestheengine.
Note:Donotbrushthedirtoffthelter;
brushingforcesdirtintothebers.
6.Removethedirtfromtheair-lterbodyandthe
coverusingamoistrag.
Important:Donotwipedirtintotheairduct.
7.Installthefoampre-lterandthepaperairlter
intotheairlter.
8.Installthecover.
ChangingtheEngineOil
ServiceInterval:Aftertherst5hours
Yearly
Engineoilcapacity:0.5L(18oz)
Oilviscosity:SAE30orSAE10W-30detergentoil
APIserviceclassication:SJorhigher
Note:Runtheengineafewminutesbeforechanging
theoiltowarmit.Warmoilowsbetterandcarries
morecontaminants.
1.Movethemachinetoalevelsurface.
2.RefertoPreparingforMaintenance(page21).
3.Removethedipstickbyrotatingthecap
counterclockwiseandpullingitout(Figure40).
g195252
Figure40
1.Dipstick
4.Tipthemachineontoitsside(sothattheair
lterisup)todraintheusedoilfromtheoil-ll
tube(Figure41).
22

Toro Super Recycler 20383 Specifications

General

Brand	Toro
Model	Super Recycler 20383
Category	Lawn Mower
Type	Walk-Behind
Engine	Briggs & Stratton
Engine Displacement	163 cc
Drive System	Personal Pace Rear-Wheel Drive
Deck Material	Cast Aluminum
Mulching Capability	Yes
Bagging Capability	Yes
Side Discharge	Yes
Starting System	Recoil
Cutting Height Adjustment	4-point
Fuel Capacity	0.25 gallons
Starter Type	Pull Cord
Cutting Width	22 inches
