Toro Super Recycler 20383 User Manual

4
FillingtheEnginewithOil
NoPartsRequired
Procedure
Important:Yourmachinedoesnotcomewithoil
intheengine.Beforestartingtheengine,llthe
enginewithoil.
Engineoilcapacity:0.5L(18oz)
Oilviscosity:SAE30orSAE10W-30detergentoil
APIserviceclassication:SJorhigher
1.Movethemachinetoalevelsurface.
2.Waitfor3to5minutesfortheoiltosettle.
3.Removethedipstick(Figure8)andpourabout
3/4ofthecrankcasecapacityofthespecied
oilintotheoil-lltube.
g195250
Figure8
1.Full3.Low
2.High
4.Wipeoffthedipstickendwithacleancloth.
5.Insertthedipstickintotheoil-lltube,butdonot
screwitin,thenremovethedipstick.
6.Readtheoillevelonthedipstick(Figure8).
•IftheoilisbelowtheAddmarkonthe
dipstick,slowlypourasmallamountofoil
intotheoil-lltube,wait3minutes,andthen
repeatsteps3through5untiltheoillevelis
attheFullmarkonthedipstick
•IftheoilisabovetheFullmarkonthe
dipstick,draintheexcessoiluntiltheoillevel
isattheFullmarkonthedipstick.T odrain
theexcessoil,refertoChangingtheEngine
Oil(page22).
Important:Iftheoillevelinthecrankcase
istoolowortoohighandyourunthe
engine,youmaydamagetheengine.
7.Installthedipstickintotheoil-lltubesecurely.
Important:Checktheengine-oillevelbefore
eachuseandaddoilasneeded;referto
CheckingtheEngine-OilLevel(page11).
5
AssemblingtheGrassBag
NoPartsRequired
Procedure
1.Slipthegrassbagovertheframeasshownin
Figure9.
g027257
Figure9
1.Handle
3.Grassbag
2.Frame
Note:Donotslipthebagoverthehandle
(Figure9).
2.Hookthebottomchannelofthebagontothe
bottomoftheframe(Figure10).
8

Toro Super Recycler 20383 Specifications

General

Brand	Toro
Model	Super Recycler 20383
Category	Lawn Mower
Type	Walk-Behind
Engine	Briggs & Stratton
Engine Displacement	163 cc
Drive System	Personal Pace Rear-Wheel Drive
Deck Material	Cast Aluminum
Mulching Capability	Yes
Bagging Capability	Yes
Side Discharge	Yes
Starting System	Recoil
Cutting Height Adjustment	4-point
Fuel Capacity	0.25 gallons
Starter Type	Pull Cord
Cutting Width	22 inches
