Side-Dischargingthe
Clippings
Usetheside-dischargefeatureforcuttingverytall
grass.
Ifthebagisonthemachine,removeitandinsertthe
rear-dischargeplug;refertoRemovingtheGrassBag
(page16)beforeside-dischargingtheclippings.
Important:Ensurethattherear-dischargeplug
islockedinplace.Tolocktheplug:Raisethe
dischargedoor(Figure32),rmlypushtheplug
inuntilitsnapsintoplacebehindthetabs,and
rotatetheleverontheplugtotheleft(Figure31).
g017463
Figure32
1.Dischargedoor2.Rear-dischargeplug
Note:T ounlocktheplug,rotatetheleverontheplug
totheright(Figure31).
WARNING
Thebladeissharp;contactingthebladecan
resultinseriouspersonalinjury.
Stoptheengineandwaitforallmovingparts
tostopbeforeleavingtheoperatingposition.
InstallingtheSide-Discharge
Chute
1.Unlocktheside-dischargedoor(Figure33).
g002590
Figure33
2.Liftopentheside-dischargedoor(Figure34).
g002591
Figure34
3.Installtheside-dischargechuteandclosethe
doorontothechute(Figure35).
g002592
Figure35
RemovingtheSide-Discharge
Chute
Toremovetheside-dischargechute,reversethe
stepsabove.
Important:Locktheside-dischargedoorafter
youcloseit(Figure36).
g002593
Figure36
OperatingTips
GeneralMowingTips
•Inspecttheareawhereyouwillusethemachine
andremoveallobjectsthatthemachinecould
throw.
•Avoidstrikingsolidobjectswiththeblade.Never
deliberatelymowoveranyobject.
•Ifthemachinestrikesanobjectorstartstovibrate,
immediatelyshutofftheengine,disconnect
18

Toro Super Recycler 20383 Specifications

General

Brand	Toro
Model	Super Recycler 20383
Category	Lawn Mower
Type	Walk-Behind
Engine	Briggs & Stratton
Engine Displacement	163 cc
Drive System	Personal Pace Rear-Wheel Drive
Deck Material	Cast Aluminum
Mulching Capability	Yes
Bagging Capability	Yes
Side Discharge	Yes
Starting System	Recoil
Cutting Height Adjustment	4-point
Fuel Capacity	0.25 gallons
Starter Type	Pull Cord
Cutting Width	22 inches
