g027258
Figure10
3.Hookthetopandsidechannelsofthebagonto
thetopandsidesoftheframe,respectively
(Figure10).
ProductOverview
g195016
Figure11
1.Handle
7.Sparkplug
2.Blade-controlbar8.Dischargedoor
3.Engine-stopswitch
9.Oilll/Dipstick
4.Fuel-tankcap10.Handlelever
5.Airlter
11.Recoil-starthandle
6.Cutting-heightlever(4)12.Control-barlock
g007407
Figure12
1.Grassbag
3.Rear-dischargeplug
(installed)
2.Side-dischargechute
9
