Setup
Important:Removeanddiscardtheprotective
plasticsheetthatcoverstheengineandanyother
plasticorwrappingonthemachine.
1
InstallingtheBlade-Control
Bar
NoPartsRequired
Procedure
Installtheblade-controlbarintotheupperhandle
(Figure4).
g003116
Figure4
2
AssemblingandUnfolding
theHandle
NoPartsRequired
Procedure
WARNING
Assemblingandunfoldingthehandle
improperlycandamagethecables,causing
anunsafeoperatingcondition.
•Donotdamagethecableswhen
assemblingandunfoldingthehandle.
•Ensurethatthecablesareroutedtothe
outsideofthehandle.
•Ifacableisdamaged,contactan
AuthorizedServiceDealer.
1.Raisetherearofthemachinehousingtoits
highestcutting-heightsettingbymovingthe2
rearcutting-heightleversallthewayforward;
refertoAdjustingtheCuttingHeight(page11).
2.Attachthehandleendstothemachinehousing
with2washersand2handlebolts(Figure5),
butdonottightenthehandlebolts.
g017457
Figure5
1.Washer3.Handleend
2.Handlebolt
Important:Routethecablestotheoutside
ofthehandle(Figure5).
3.Rotatethehandlerearward(Figure6).
6

Toro Super Recycler 20383 Specifications

General

Brand	Toro
Model	Super Recycler 20383
Category	Lawn Mower
Type	Walk-Behind
Engine	Briggs & Stratton
Engine Displacement	163 cc
Drive System	Personal Pace Rear-Wheel Drive
Deck Material	Cast Aluminum
Mulching Capability	Yes
Bagging Capability	Yes
Side Discharge	Yes
Starting System	Recoil
Cutting Height Adjustment	4-point
Fuel Capacity	0.25 gallons
Starter Type	Pull Cord
Cutting Width	22 inches
