Toro Super Recycler 20383 User Manual

g003133
Figure45
1.Bladenuts4.Bladedriver
2.Stiffener
5.Disk
3.Blade6.Blade-brake-clutchshield
4.Removetheblade(Figure45).
5.Removethebladedriveranddisk(Figure45).
6.Removetheblade-brake-clutchshield(Figure
45).
7.Brushorblowoutdebrisfromtheinsideofthe
shieldandaroundalltheparts.
8.Installtheblade-brake-clutchshieldthatyou
previouslyremoved.
9.Installthebladedriveranddiskthatyou
previouslyremoved.
10.Installthebladeandthestiffenerthatyou
previouslyremoved(Figure45).
11.Installthebladenutsandtorquethemto20to
37N∙m(15to27ft-lb).
AdjustingtheSelf-Propel
Drive
Wheneveryouinstallanewself-propelcableorif
theself-propeldriveisoutofadjustment,adjustthe
self-propeldrive.
1.Turntheadjustmentknobcounterclockwiseto
loosenthecableadjustment(Figure46).
g027231
Figure46
1.Handle(leftside)
4.Turntheknobclockwiseto
tightentheadjustment.
2.Adjustmentknob5.Turntheknob
counterclockwiseto
loosentheadjustment.
3.Self-propel-drivecable
2.Adjustthetensiononthecable(Figure46)by
pullingitbackorpushingitforwardandholding
thatposition.
Note:Pushthecabletowardtheengineto
increasethetraction;pullthecableawayfrom
theenginetodecreasethetraction.
3.Turntheadjustmentknobclockwisetotighten
thecableadjustment.
Note:Tightentheknobrmlybyhand.
25

Toro Super Recycler 20383 Specifications

General

Brand	Toro
Model	Super Recycler 20383
Category	Lawn Mower
Type	Walk-Behind
Engine	Briggs & Stratton
Engine Displacement	163 cc
Drive System	Personal Pace Rear-Wheel Drive
Deck Material	Cast Aluminum
Mulching Capability	Yes
Bagging Capability	Yes
Side Discharge	Yes
Starting System	Recoil
Cutting Height Adjustment	4-point
Fuel Capacity	0.25 gallons
Starter Type	Pull Cord
Cutting Width	22 inches
