7 - 12 TimeCutter™ Z Service Manual
MOWER DECKS
7
Remove the spindle housing assembly from the
deck. Use a long punch to drive the bearings
from the spindle housing.
There is a spacer between the two bearings.
The spindle housing assembly consists of a
casting, two bearings, and a spacer.
0702-0717
0702-0718
0702-0720
