CHASSIS
TimeCutter™ Z Service Manual 6 - 3
6
Remove the E-clip and washer at the bottom of
the damper.
Remove the bolt at the top of the damper and
remove the damper.
0702-0601
0702-0602
Remove and Replace Dampers
