4 - 4 TimeCutter™ Z Service Manual
ENGINE
4
The air cleaner assembly consists of a paper
filter element and a foam precleaner.
To clean the paper element, tap lightly on a flat
surface to remove dust and dirt. Inspect the
element for tears, oil contamination, and damage
to the rubber seal.
NOTE: Never clean the paper element with
compressed air or solvents. If the element is
dirty or damaged, replace it immediately.
(A) Paper Element
(B) Foam Precleaner
(C) Cover
A
B
C
The air cleaner assembly consists of a paper
filter element and a foam precleaner.
To clean the paper element, tap lightly on a flat
surface to remove dust and dirt. Inspect the
element for tears, oil contamination, and damage
to the rubber seal.
NOTE: Never clean the paper element with
compressed air or solvents. If the element is
dirty or damaged, replace it immediately.
(A) Paper Element
(B) Foam Precleaner
(C) Cover
A
B
C
The air cleaner assembly consists of a paper
filter element and a foam precleaner.
To clean the paper element, tap lightly on a flat
surface to remove dust and dirt. Inspect the
element for tears, oil contamination, and damage
to the rubber seal.
NOTE: Never clean the paper element with
compressed air or solvents. If the element is
dirty or damaged, replace it immediately.
(A) Cover
(B) Air Filter
B
A
0702-0404
0702-0405
0702-0406
Briggs & Stratton Air Cleaner
Kohler Air Cleaner
Kawasaki Air Cleaner
