Toro Titan Z4800 74812 User Manual

Tires&Wheels
Drive
FrontCaster
Pneumatic(Air-Filled)
Pneumatic
(Air-Filled)
DeckSize
4852AllDecks
Quantity
222
TreadSizeTurfT ecTurfT ec
AllDecks
Size
20x8.00-820x10.00-810x4
PlyRating44
Pressure13psi
(90kPa)
13psi
(90kPa)
13psi
(90kPa)
CuttingDeck
•CuttingWidth:
–48inchDeck:48inches(122cm)
–52inchDeck:52inches(132cm)
•Discharge:Side
•BladeSize:(3ea.)
–48inchDeck:16.25inches(41.3cm)
–52inchDeck:18.00inches(45.7cm)
•BladeSpindles:Solidsteelspindleswithno
maintenancebearings.
•DeckDrive:Electricclutchmountedonvertical
engineshaft.Bladesaredrivenbyonebelt
(w/self-tensioningidler)directfromtheengine.
•Deck:Fulloatingdeckisattachedtoout-front
supportframe.Maximumturfprotectionisprovided
withthreeanti-scalprollers(bothdecksizes).
Deckdesignallowsforbagging,mulchingorside
discharge.
•DeckDepth:
–46inchDeck:5.0inches(12.7cm)
–52inchDeck:5.0inches(12.7cm)
•CuttingHeightAdjustment:Afootdeckliftleveris
usedtoadjustthecuttingheightfrom11/2inch
(3.8cm)to41/2inches(11.4cm)in1/2inch(1.3
cm)increments.
•MulchingKit:Optional.
Dimensions
OverallWidth:
48inchDeck52inchDeck
WithoutDeck45.5inches
(116cm)
47.0inches
(119cm)
48inchDeck52inchDeck
DeectorUp
48.3inches
(122cm)
53.0inches
(135cm)
DeectorDown
59.4inches
(151cm)
64.2inches
(163cm)
OverallLength:
48inchDeck52inchDeck
73.4inches(186cm)73.4inches(186cm)
OverallHeight:
48inchDeck52inchDeck
41.8inches(106cm)41.8inches(106cm)
TreadWidth:(CentertoCenterofTires,
Widthwise)
48inchDeck52inchDeck
DriveWheels36.0inches
(91cm)
36.8inches
(93cm)
CasterWheels
33.5inches
(85cm)
33.5inches
(85cm)
WheelBase:(CenterofCasterTireto
CenterofDriveTire)
48inchDeck52inchDeck
48.9inches(124cm)48.9inches(124cm)
CurbWeight:
48inchDeck52inchDeck
645lb(293kg)660lb(299kg)
TorqueRequirements
BoltLocationTorque
SpindlePulleyNut95-100ft-lb(1291-142N-m)
BladeMountingBolt
45-55ft-lb(61-75N-m)
EngineMountingBolts
27-33ft-lb(37-45N-m)
Anti-ScalpRollerNylocNut27-33ft-lb(37-45N-m)
WheelLugNuts
70-90ft-lb(95-122N-m)
ClutchMountingBolt(secured
withthreadlocker)
50-55ft-lb(68-75N-m)
SparkPlug15ft-lb(20N-m)
15
