Toro Titan Z4800 74812 User Manual

Forward
1.Movetheleverstothecenter,unlockedposition.
2.Togoforward,slowlypushthemotioncontrol
leversforward(Figure14).
Figure14
1.Neutralposition3.Backward
2.Centerunlockposition
4.Forward
Togostraight,applyequalpressuretobothmotion
controllevers(Figure14).
Toturn,pullbackonthemotioncontrollever
towardthedirectionyouwanttoturn(Figure14).
Thefartheryoumovethemotioncontrolleversin
eitherdirection,thefasterthemachinewillmovein
thatdirection.
Tostop,pullthemotioncontrolleverstoneutral.
Backward
1.Movetheleverstothecenter,unlockedposition.
2.Togobackward,slowlypullthemotioncontrol
leversrearward(Figure14).
Togostraight,applyequalpressuretobothmotion
controllevers(Figure14).
Toturn,releasethepressureonthemotion
controllevertowardthedirectionyouwanttoturn
(Figure14).
Tostop,pushthemotioncontrolleverstoneutral.
StoppingtheMachine
Tostopthemachine,movethemotioncontrolleversto
neutralandoutwardtotheneutralposition,disengage
thebladecontrolswitch,movethethrottleleverto
betweenFastandhalfthrottle,andturntheignitionkey
tooff.Remembertoremovethekeyfromtheignition
switch.
TrackingAdjustment
Ifthemachineturnsrightorleftwhenhandlesare
pushedforwardtogether,adjustthestopontheside
oppositethedirectionofturn(Figure15).Loosenthe
screwsthatholdthemotioncontrollimiterstop.Move
thestopbackuntiltheunitdrivesstraight.Tighten
thescrewstolockthestopinplace.Readjusthandles
ifnecessary.
Figure15
1.Controlarmshaft
3.Adjuststop
2.Limiterstopscrews
Childrenorbystandersmaybeinjuredifthey
moveorattempttooperatethemowerwhileit
isunattended.
Alwaysremovetheignitionkeyandmovethe
motioncontrolleversoutwardtotheneutral
positionandapplytheparkingbrakewhen
leavingthemachineunattended,evenifjustfor
afewminutes.
21
