Premaintenance

Procedures

RaisingtheSeat

Makesurethemotioncontrolleversarelockedinthe

neutralposition.Lifttheseatforwarduntilthelanyard

istight.Thefollowingcomponentscanbeaccessedby

raisingtheseat:

•Auxiliary12VPlug(12Vaccessoryupto15amp)

•Fuses

•Batterycables

AccessingtheBattery

Thebatteryislocatedundertheseat.Toaccess,raise

theseat(Figure21).

Figure21

1.Auxiliary12VPlug

3.Seat

2.Battery

Lubrication

GreasingtheBearings

GreaseType:NGLIgrade#2multi-purposegungrease.

Greasethefrontcasterpivotsandwheels(Figure22).

G007184

Figure22

1.Frontcastertire

1.Parkthemachineonalevelsurfaceanddisengage

thebladecontrolswitch.

2.Movethemotioncontrolleversoutwardtothe

neutralposition,engageparkingbrake,stopthe

engine,removethekey,andwaitforallmovingparts

tostopbeforeleavingtheoperatingposition.

3.Cleanthegreasettings(Figure22andFigure23)

witharag.Makesuretoscrapeanypaintoffofthe

frontofthetting(s).
