Specifications
• Power Source – 120 VAC, 60 Hz
• Power Source – 220/240 VAC, 50 Hz (Export)
• Transformer Output – 24 VAC, 30 VA
• Fuses – F1 (Control Circuit) 3/4 Amp
F2 (Station and Pump/Master Valve Output) 1-1/2 Amp
• Maximum Number of Plastic Valves Allowed Per Station – Two Toro 1 in. Electric
• Output to Valves – .01 Amp to .374 Amp @ 24 VAC
• Output to Pump Relay/Master Valve – .01 Amp to .374 Amp @ 24 VAC
• Cabinet – Plastic, Indoor/Outdoor, Wall Mount
Dimensions - 13 in. H x 9 in. W x 3-1/4 in. D
(33 cm H x 23 cm W x 8.3 cm D)
Metal, Lockable, Indoor/Outdoor, Wall Mount
Dimensions - 13-1/2 in. H x 9 in. W x 3-3/4 in. D
(34.3 cm H x 23 cm W x 9.5 cm D)
Conduit Access – 1/2 in. (13 mm) Power, 1 in. (25 mm) Field
• UL, TUV and CSA Approved
Class B Irrigation Controller
This equipment generates and uses radio frequency energy and if not installed and
used properly, that is, in strict accordance with the manufacturer's instructions,
may cause interference to radio and television reception. It has been type tested
and found to comply with the limits for a Class B computing device in accordance
with the specifications in Subpart J of Part 15 of FCC Rules, which are designed to
provide reasonable protection against such interference in a residential
installation. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient the receiving antenna.
• Relocate the irrigation controller with respect to the receiver.
• Move the irrigation controller away from the receiver.
• Plug the irrigation controller into a different outlet so that the irrigation
controller and receiver are on different branch circuits.
If necessary, the user should consult the dealer or an experienced radio/television
technician for additional suggestions. The user may find the following booklet
prepared by the Federal Communications Commission helpful: "How to Identify and
Resolve Radio-TV Interference Problems". This booklet is available from the U.S.
Government Printing Office, Washington, DC 20402. Stock No. 004-000-00345-4.
22
