2
ConnectingtheBattery
TCModelsOnly
NoPartsRequired
Procedure
WARNING
Incorrectbatterycableroutingcoulddamage
themachineandcables,causingsparks.
Sparkscancausethebatterygasesto
explode,resultinginpersonalinjury.
•Alwaysdisconnectthenegative(black)
batterycablebeforedisconnectingthe
positive(red)cable.
•Alwaysconnectthepositive(red)battery
cablebeforeconnectingthenegative
(black)cable.
1.Connectthepositivebatterycable(red)tothe
positive(+)terminalofthebatteryandsecure
thecableusingtheboltandnuts(Figure4).
2.Slidetheinsulatorbootoverthepositiveterminal
(Figure4).
Note:Theinsulatorbootpreventsapossible
short-to-groundfromoccurring.
3.Connectthenegativebatterycable(black)tothe
negative(–)terminalofthebatteryandsecure
thecableusingtheboltandnuts(Figure4).
g357128
Figure4
1.Negativebatterycable
(black)
4.Bolt
2.Positivebatterycable(red)
5.Nuts
3.Insulatorboot(positive
batterycable)
10
