InstallingtheRollover
ProtectionSystem(ROPS)
ForStandard(2-Person)Models
Partsneededforthisprocedure:
1
Left,frontrollbarassembly
1
Right,frontrollbarassembly
1
Left,rearrollbarassembly
1Right,rearrollbarassembly
1Frontcrosslink
1Rearcrosslink
1
Seatpanel
2
Shoulderrestraint
8
Hex-headbolt(3/8x1-1/4inches)
12
Carriagebolt(5/16x3/4inch)
4
Hex-washerheadbolt(5/16x3/4inch)
10
Hex-washerheadbolt(1/4x3/4inch)
2
Hex-washerheadbolt(1/4x1inch)
2
Button-headbolt(5/16x1-1/2inches)
2
Flange-headbolt(3/8x2-1/4inches)
14
Locknut(5/16inch)
10
Locknut(3/8inch)
2
Locknut(1/4inch)
2
Locknut(7/16inch)
Procedure
1.Raisethecargobed(Figure7).
g361797
Figure7
13
