7
InstallingtheRollover
ProtectionSystem(ROPS)
ForCrew(4-Person)Models
Partsneededforthisprocedure:
1
Left,frontrollbarassembly
1
Right,frontrollbarassembly
1
Left,rearrollbarassembly
1Right,rearrollbarassembly
1
Left,middlerollbarassembly
1Right,middlerollbarassembly
2Rollbarconnectorassembly
1Rearseathandleassembly
1Frontcrosslink
1Middlecrosslink
1Rearcrosslink
2
Seatpanel
4
Shoulderrestraint
20
Hex-headbolt(3/8x1-1/4inches)
16
Carriagebolt(5/16x3/4inch)
8
Hex-washerheadbolt(5/16x3/4inch)
24
Hex-washerheadbolt(1/4x3/4inch)
2
Hex-washerheadbolt(1/4x1inch)
4
Button-headbolt(5/16x1-1/2inches)
2
Flange-headbolt(3/8x2-1/4inches)
4
Flange-headbolt(3/8x1inch)
20
Locknut(5/16inch)
26
Locknut(3/8inch)
2
Locknut(1/4inch)
4
Locknut(7/16inch)
4
Clip(1/4inch)
Procedure
1.Raisethecargobed(Figure30).
g364836
Figure30
31
