g036853
g036855
Figure 69
Charging the Battery
W ARNING
Charging the battery produces gasses that
can explode.
Never smoke near the battery and keep sparks
and ames away from the battery .
Important: Always keep the battery fully charged
(1.265 specic gravity). This is especially
important to prevent battery damage when the
temperature is below 0°C (32°F).
1. Remove the battery from the chassis; refer to
Removing the Battery ( page 53 ) .
2. Charge the battery for 10 to 15 minutes at 25 to
30 A or for 30 minutes at 10 A.
Note: Do not overcharge the battery .
3. When the battery is fully charged, unplug
the charger from the electrical outlet, then
disconnect the charger leads from the battery
posts ( Figure 70 ).
4. Install the battery in the machine and connect
the battery cables; refer to Installing the Battery
( page 55 ) .
Note: Do not run the machine with the battery
disconnected; electrical damage may occur .
g000960
Figure 70
1. Positive (+) battery post 3. Red (+) charger lead
2. Negative (–) battery post 4. Black (–) charger lead
54
