8-11
OPTIONAL DEVICES
Battery Charger
The battery charger (PA3091U) was designed for an earlier computer model. To
charge batteries for the PORTÉGÉ 2010, it must be connected to an optional Battery
Charge cable that is supplied only with the Slim Port Replicator. When the battery
charger is connected to the Battery Charge cable, you can use it to charge the main
battery and the optional High Capacity 2nd Battery Pack. For details, refer to the
information sheet describing use of the Slim Port Replicator and Battery Charge
cable.
USB FDD Kit
The 3 1/2" external diskette drive module can be connected to the USB port. For
details on connecting the 3 1/2" external diskette drive module, refer to Chapter 4,
Operating Basics.
Slim Port Replicator
In addition to the ports available on the computer, the Slim Port Replicator provides,
an external monitor port, four USB ports, a port for charging a High Capacity 2nd
Battery Pack, a LAN jack and a DC-IN socket. The Slim Port Replicator connects
directly to the docking interface on the bottom of the computer. The AC adaptor
connects the Slim Port Replicator to a power source.
CAUTION: The computer must be configured properly before connecting
to a LAN. Logging onto a LAN using the computer’s default settings
could cause a malfunction in LAN operation. Check with your LAN
administrator regarding set-up procedures.
Ports
The following ports and accessories are available on the Slim Port Replicator.
◆ One RJ45 LAN jack
◆ External monitor port
◆ DC IN socket
◆ Universal Serial Bus (four) ports
◆ Port to charge a High Capacity 2nd Battery Pack
Slim Port Replicator
