Toshiba MMY-MUP2401HT8P-A User Manual

Outdoor Unit
PS sensor characteristics
0 to 2.24 MPa (0.5 to 5V output for 0 to 2.24 MPa)
Voltage readings across pins 2 and 3 of CN500 on indoor unit main P.C. board (with negative-side probe of
multimeter placed on pin 3)
VOLT
PS
(MPa)
PS
(kg/cm
2
)
VOLT
PS
(MPa)
PS
(kg/cm
2
)
VOLT
PS
(MPa)
PS
(kg/cm
2
)
VOLT
PS
(MPa)
PS
(kg/cm
2
)
VOLT
PS
(MPa)
PS
(kg/cm
2
)
0.01 0.00 0.0 1.00 0.25 2.6 2.00 0.75 7.7 3.00 1.25 12.7 4.00 1.75 17.8
0.03 0.00 0.0 1.02 0.26 2.7 2.02 0.76 7.8 3.02 1.26 12.8 4.01 1.76 17.9
0.05 0.00 0.0 1.04 0.27 2.8 2.04 0.77 7.9 3.04 1.27 12.9 4.03 1.77 18.0
0.07 0.00 0.0 1.06 0.28 2.9 2.06 0.78 8.0 3.05 1.28 13.0 4.05 1.78 18.1
0.09 0.00 0.0 1.08 0.29 3.0 2.08 0.79 8.1 3.07 1.29 13.1 4.07 1.79 18.2
0.11 0.00 0.0 1.10 0.30 3.1 2.10 0.80 8.2 3.09 1.30 13.2 4.09 1.80 18.3
0.13 0.00 0.0 1.12 0.31 3.2 2.12 0.81 8.3 3.11 1.31 13.3 4.11 1.81 18.4
0.14 0.00 0.0 1.14 0.32 3.3 2.14 0.82 8.4 3.13 1.32 13.4 4.13 1.82 18.5
0.16 0.00 0.0 1.16 0.33 3.4 2.16 0.83 8.5 3.15 1.33 13.5 4.15 1.82 18.6
0.18 0.00 0.0 1.18 0.34 3.5 2.18 0.84 8.6 3.17 1.34 13.6 4.17 1.83 18.7
0.20 0.00 0.0 1.20 0.35 3.6 2.20 0.85 8.7 3.19 1.35 13.7 4.19 1.84 18.8
0.22 0.00 0.0 1.22 0.36 3.7 2.21 0.86 8.8 3.21 1.36 13.8 4.21 1.85 18.9
0.24 0.00 0.0 1.24 0.37 3.8 2.23 0.87 8.9 3.23 1.37 13.9 4.23 1.86 19.0
0.26 0.00 0.0 1.26 0.38 3.9 2.25 0.88 9.0 3.25 1.38 14.0 4.25 1.87 19.1
0.28 0.00 0.0 1.28 0.39 4.0 2.27 0.89 9.1 3.27 1.39 14.1 4.27 1.88 19.2
0.30 0.00 0.0 1.30 0.40 4.1 2.29 0.90 9.2 3.29 1.40 14.2 4.29 1.89 19.3
0.32 0.00 0.0 1.32 0.41 4.2 2.31 0.91 9.3 3.31 1.41 14.3 4.30 1.90 19.4
0.34 0.00 0.0 1.34 0.42 4.3 2.33 0.92 9.4 3.33 1.42 14.4 4.32 1.91 19.5
0.36 0.00 0.0 1.36 0.43 4.4 2.35 0.93 9.5 3.35 1.42 14.5 4.34 1.92 19.6
0.38 0.00 0.0 1.38 0.44 4.5 2.37 0.94 9.6 3.37 1.43 14.6 4.36 1.93 19.7
0.40 0.00 0.0 1.39 0.45 4.6 2.39 0.95 9.7 3.39 1.44 14.7 4.38 1.94 19.8
0.42 0.00 0.0 1.41 0.46 4.7 2.41 0.96 9.8 3.41 1.45 14.8 4.40 1.95 19.9
0.44 0.00 0.0 1.43 0.47 4.8 2.43 0.97 9.9 3.43 1.46 14.9 4.42 1.96 20.0
0.46 0.00 0.0 1.45 0.48 4.9 2.45 0.98 10.0 3.45 1.47 15.0 4.44 1.97 20.1
0.48 0.00 0.0 1.47 0.49 5.0 2.47 0.99 10.1 3.46 1.48 15.1 4.46 1.98 20.2
0.50 0.00 0.0 1.49 0.50 5.1 2.49 1.00 10.2 3.48 1.49 15.2 4.48 1.99 20.3
0.52 0.01 0.1 1.51 0.51 5.2 2.51 1.01 10.3 3.50 1.50 15.3 4.50 2.00 20.4
0.54 0.02 0.2 1.53 0.52 5.3 2.53 1.02 10.4 3.52 1.51 15.4 4.52 2.01 20.5
0.55 0.03 0.3 1.55 0.53 5.4 2.55 1.02 10.5 3.54 1.52 15.5 4.54 2.02 20.6
0.57 0.04 0.4 1.57 0.54 5.5 2.57 1.03 10.6 3.56 1.53 15.6 4.56 2.03 20.7
0.59 0.05 0.5 1.59 0.55 5.6 2.59 1.04 10.7 3.58 1.54 15.7 4.58 2.04 20.8
0.61 0.06 0.6 1.61 0.56 5.7 2.61 1.05 10.8 3.60 1.55 15.8 4.60 2.05 20.9
0.63 0.07 0.7 1.63 0.57 5.8 2.63 1.06 10.9 3.62 1.56 15.9 4.62 2.06 21.0
0.65 0.08 0.8 1.65 0.58 5.9 2.64 1.07 11.0 3.64 1.57 16.0 4.64 2.07 21.1
0.67 0.09 0.9 1.67 0.59 6.0 2.66 1.08 11.1 3.66 1.58 16.1 4.66 2.08 21.2
0.69 0.10 1.0 1.69 0.60 6.1 2.68 1.09 11.2 3.68 1.59 16.2 4.68 2.09 21.3
0.71 0.11 1.1 1.71 0.61 6.2 2.70 1.10 11.2 3.70 1.60 16.3 4.70 2.10 21.4
0.73 0.12 1.2 1.73 0.62 6.3 2.72 1.11 11.3 3.72 1.61 16.4 4.71 2.11 21.5
0.75 0.13 1.3 1.75 0.62 6.4 2.74 1.12 11.4 3.74 1.62 16.5 4.73 2.12 21.6
0.77 0.14 1.4 1.77 0.63 6.5 2.76 1.13 11.5 3.76 1.63 16.6 4.75 2.13 21.7
0.79 0.15 1.5 1.79 0.64 6.6 2.78 1.14 11.6 3.78 1.64 16.7 4.77 2.14 21.8
0.81 0.16 1.6 1.80 0.65 6.7 2.80 1.15 11.7 3.80 1.65 16.8 4.79 2.15 21.9
0.83 0.17 1.7 1.82 0.66 6.8 2.82 1.16 11.8 3.82 1.66 16.9 4.81 2.16 22.0
0.85 0.18 1.8 1.84 0.67 6.9 2.84 1.17 11.9 3.84 1.67 17.0 4.83 2.17 22.1
0.87 0.19 1.9 1.86 0.68 7.0 2.86 1.18 12.0 3.86 1.68 17.1 4.85 2.18 22.2
0.89 0.20 2.0 1.88 0.69 7.1 2.88 1.19 12.1 3.88 1.69 17.2 4.87 2.19 22.3
0.91 0.21 2.1 1.90 0.70 7.2 2.90 1.20 12.2 3.89 1.70 17.3 4.89 2.20 22.4
0.93 0.22 2.2 1.92 0.71 7.3 2.92 1.21 12.3 3.91 1.71 17.4 4.91 2.21 22.5
0.95 0.22 2.3 1.94 0.72 7.4 2.94 1.22 12.4 3.93 1.72 17.5 4.93 2.22 22.6
0.96 0.23 2.4 1.96 0.73 7.5 2.96 1.23 12.5 3.95 1.73 17.6 4.95 2.22 22.7
0.98 0.24 2.5 1.98 0.74 7.6 2.98 1.24 12.6 3.97 1.74 17.7 4.97 2.23 22.8
4.99 2.24 22.9
- 246 -
