[5d] External static pressure & High-ceiling adjustment
<4-way Cassette, 2-way Cassette, 1-way Cassette SH Type>
Set data
High-ceiling adjustment
0000 Standard (Factory default)
0001 High ceiling 1
0003 High ceiling 3
<Compact 4-way Cassette>
Set data
High-ceiling adjustment
0000 Standard (Factory default)
0001 High ceiling 1 (UP015 only)
0003 High ceiling 3 (UP015 only)
<Under Ceiling type>
Set data
High-ceiling adjustment
0000 Standard (Factory default)
0003 High ceiling 1
<Concealed Duct Type>
Set data
External static pressure
0000 40 Pa UP024 to 030 (Factory default)
0001 30 Pa UP007 to 018 (Factory default)
0002 65 Pa —
0003 50 Pa UP036 to 056 (Factory default)
0004 80 Pa —
0005 100 Pa —
0006 120 Pa —
<Slim Duct type>
Set data
External static pressure
0000 10 Pa Standard (Factory default)
0001 20 Pa High static pressure 1
0003 35 Pa High static pressure 2
0006 50 Pa High static pressure 3
<Concealed Duct High Static Pressure Type (6 HP or less)>
Set data
External static pressure
0000 100 Pa Standard (Factory default)
0001 50 Pa —
0002 75 Pa —
0003 150 Pa —
0004 125 Pa —
0005 175 Pa —
0006 200 Pa —
<Concealed Duct High Static Pressure Type (8, 10 HP)>
Set data
External static pressure
0000 150 Pa Standard (Factory default)
0001 50 Pa —
0002 83 Pa —
0003 217 Pa —
0004 117 Pa —
0005 183 Pa —
0006 250 Pa —
