User’s Manual 2-1
The Grand Tour
Chapter 2
The Grand Tour
This chapter identifies the various components of your computer. Become
familiar with each component before you operate the computer.
Front with the display closed
The following figure shows the computer's front with its display panel in the
closed position.
The front of the computer with the display closed
2
5 6
7
8 9
1
3
4
1. Infrared Receiver Window
2. Wireless Communication Switch
3. Wireless Activity LED
4. Multiple Digital Media Card Slot
5. DC in LED
6. Power LED
7. Battery LED
8. Disk LED
9. Multiple Digital Media Card Slot LED
Infrared Receiver
Window
An infrared receiver window is provided with
some models. This is a sensor window that
receives signals from the remote control provided
with your computer.
