Toshiba Satellite A50 User Manual

F-2 User’s Manual
Internal Modem Guide
Removing the internal modem
To remove the internal modem, follow the steps below.
1. Save your data and turn off the computer.
2. Disconnect the AC adaptor and any other peripheral device.
3. Turn the computer upside down and remove the battery pack.
4. Loosen the screw on the memory module cover next to the modem
cover to remove the cover.
5. Loosen the screw securing the cover.
6. Remove the modem cover.
7. Remove two screws and remove the modem board.
8. Disconnect the modem cable.
9. Secure the modem cover with one screw.
10. Reinstall the memory module cover and tighten the screw.
11. Install the battery pack.
Refer to the installation procedures for details.
A02-0604JP

Toshiba Satellite A50 Specifications

General

Processor	Intel Pentium M or Intel Celeron M
RAM	256MB - 2GB DDR SDRAM
Storage	40GB HDD
Display	15.0" XGA (1024x768)
Operating System	Windows XP Home/Professional
Optical Drive	DVD-ROM
Battery	Li-Ion
Networking	10/100 Ethernet, 56k modem, optional Wi-Fi
Ports	3 x USB 2.0, 1 x VGA
Audio	Built-in stereo speakers
