User’s Manual 2-3
The Grand Tour
Right side
Figure 2-3 shows the computer’s right side.
Figure 2-3 The right side of the computer
Keep foreign objects out of the USB connectors. A pin or similar object can
damage the computer’s circuitry.
Operation of all functions of all USB devices has not been confirmed.
Some functions might not execute properly.
PC card slot A PC card slot can accommodate a 5 mm Type II
card. The slot supports 16-bit PC cards and
CardBus PC cards.
CB
Keep foreign objects out of the PC card slot. A pin or similar object can
damage the computer’s circuitry.
Security lock A security cable attaches to this slot. The
optional security cable anchors your computer to
a desk or other large object to deter theft.
Microphone jack
Headphone jack
Fixed Optical media drive
DC IN 15V jack
USB port
Volume control
Volume control Use this dial to adjust the volume of the stereo
speakers and the stereo headphones.
Headphone jack This jack outputs analog audio signals.
Microphone jack A 3.5 mm mini microphone jack enables
connection of a three-conductor mini jack for
monaural microphone input.
