6.5 V/f 5-point setting
:
V/f 5-point setting VF1 frequency
:
V/f 5-point setting VF1 voltage
:
V/f 5-point setting VF2 frequency
:
V/f 5-point setting VF2 voltage
:
V/f 5-point setting VF3 frequency
:
V/f 5-point setting VF3 voltage
:
V/f 5-point setting VF4 frequency
:
V/f 5-point setting VF4 voltage
:
V/f 5-point setting VF5 frequency
:
V/f 5-point setting VF5 voltage
⇒ For details, refer to Section 5.6,5).
6.6 Speed command switching
6.6.1 Using two types of frequency (speed) commands
: Frequency setting mode selection 1
: Frequency priority selection
: Frequency setting mode selection 2
: Speed command priority switching frequency
• Function
These parameters switch two types of frequencies
• Automatic switching by parameter setting
• Automatic switching by means of switching frequencies
• Switching with input terminal
1) Switching with input terminal board (=)
Reference can be switched if the frequency priority switching function is assigned to a terminal.
Command selected
with
Command selected
with
Operation frequency
command
A
B
A : Selects the command set with parameter . – Operation frequency command switching terminal OFF
B : Selects the command set with parameter . – Operation frequency command switching terminal ON
Ex.) When the frequency priority switching function is assigned to terminal S3.
Title Function Adjustment range Example of setting
Input terminal function selection 7 (S3) ~
(Operation frequency command
switching)
Speed command
OFF
Command selected with
ON
Command selected with
S3
CC
