E6581528
F-75
6
[Setup values of ~]
Default setting
Communication
No.
Trace (monitor) function
Communication
unit at tracing
 FD00 Output frequency 0.01Hz
 FD02 Frequency command value 0.01Hz
 FD03 Output current 0.01%
 FD04 Input voltage (DC detection) 0.01%
 FD05 Output voltage 0.01%
 FD15 Compensated frequency 0.01Hz
 FD16 Speed feedback (real-time value) 0.01Hz
 FD17 Speed feedback (1-second filter) 0.01Hz
 FD18 Torque 0.01%
 FD19 Torque command 0.01%
 FD20 Torque current 0.01%
 FD21 Exciting current 0.01%
 FD22 PID feedback value 0.01%
 FD23 Motor overload factor (OL2 data) 0.01%
 FD24 Inverter overload factor (OL1 data) 0.01%
 FD25
Regenerative braking resistance overload factor (OLr
data)
0.01%
 FD28 Regenerative braking resistor load factor (% ED) 0.01%
 FD29 Input power 0.01kW
 FD30 Output power 0.01kW
 FE39 Optional AI2 input 0.01%
 FE35 RR/S4 input 0.01%
 FE36 VI/II input 0.01%
 FE37 RX input 0.01%
 FE38 Optional AI1 input 0.01%
 FE40 FM output 0.01%
 FE41 AM output 0.01%
 FE76 Integral input power 0.01kWhr
 FE77 Integral output power 0.01kWhr
 FE60 My function monitor 1 1c
 FE61 My function monitor 2 1c
 FE62 My function monitor 3 1c
 FE63 My function monitor 4 1c
 Acquisition of trace data
Trace data is acquired through a communication device.
The VF-AS1 supports the protocols listed below.
• RS485 (Standard protocol)
