7.2.3 Setup of input terminal operation time
 Setup of response time
Title Function Adjustment range Default setting
 Input terminal 1 response time selection (F) ~ ms 
 Input terminal 2 response time selection (R) ~ ms 

Input terminal 4 response time selection
(RES)
~ ms 
 Input terminal 5~12 response time selection ~ ms 

Input terminal 13~20 response time
selection
~ ms 
: Setting when vector option unit or expansion terminal board option is used.
Note: Response time refers to the time elapsing before the inverter receives a signal from a terminal. In reality, an
extra several milliseconds is required for the inverter to produce an output.
7.2.4 Analog input filter
 Response time setting
Title Function Adjustment range Default setting
 Analog input filter
:No filter
:Filter approx. 10ms
:Filter approx. 15ms
:Filter approx. 30ms
:Filter approx. 60ms

•Function
The input/output terminal operation time setup function is used to extend response time if there is something
malfunctioning because of noise or chattering of input relay.
•Function
This function is effective to remove noise from the frequency setting circuit. If operation is unstable because of
noise, increase the time constant of the analog input filter.
