If the toilet is in a location you will not visit for a long time, drain the water.
(The water in the tank may cause malfunctions or become contaminated and cause skin irritation or other problems.)
How to drain the water
1
Drain the water from the toilet tank.
(Page 57 Step
1
,
2
)
2
Press
"Wand CLEAN" button.
Open the wand cover.
(Release the pressure from the water supply
pipe.)
3
Switch the breaker on the
distribution board to OFF.
4
Drain the pipe.
(Page 57 Step
5
)
5
Pull out the water drain lever.
Water comes out from around the wand
(about 20 seconds)
Water drain lever
6
Release your hand to return the
water drain lever to its original
position.
If water may get frozen
Add antifreeze solution in the water in the bowl to
prevent freezing.
(The antifreeze solution should not be ushed out.
Collect it before using the toilet and dispose of it.)
To use the product again
The water needs to be resupplied. (See below)
Resupplying the Water
1
Open the shutoff valve. (Page 15)
Check that water is not leaking from a pipe or the main unit.
2
If the power is not turned ON,
switch the breaker on the distribution board to ON.
The "Power" LED lights up.
3
Discharge water from the wand.
(1) Pressing down the left side of the toilet seat,
(2)
Press "Rear cleansing" button on the remote control to
discharge water from the wand.
Catch the water in a paper cup or other receptacle.
(3)
Press "Stopping" button.
If the remaining water has frozen and no water comes out
Heat the inside of the bathroom, and warm the water supply hose and shutoff valve using a cloth
soaked in warm water.
Soft cloth soaked in water
(to prevent scratching)
Paper cup
What to Do?
Long Periods of Disuse
58
