141NP−01
A85930
Cylinder Head
Cover Sub−assy
Gasket
Camshaft
Sub−assy No. 2
Camshaft
Sub−assy No. 1
Camshaft Oil
Seal Retainer
z Nozzle Holder
Seal
Nozzle Leakage
Pipe Assy
Nozzle Holder Clamp
z Fuel Injector
Back−up
Ring No. 1
Washer
Camshaft Bearing Cap
z Gasket
z Oil Seal
Oil Filler Cap Sub−assy
Plate Washer
Camshaft Timing Pulley
Timing Belt Idler Sub−assy No. 1
13 (135, 10)
20 (204, 15)
88 (899, 65)
N·m (kgf·cm, ft·lbf)
: Specified torque
z Non−reusable part
18 (184, 13)
27 (275, 20)
8.8 (90, 78 in.·lbf)
35 (357, 26)
Camshaft Carrier
x5
x4
z O−ring
z Injection Nozzle Seat
Injector Assy
20 (204, 15)
20 (204, 15)
−ENGINE MECHANICAL PARTIAL ENGINE ASSY (1CD−FTV)(From September,
2003)
14−1
1CD−FTV ENGINE REPAIR MANUAL (RM1046E)
PARTIAL ENGINE ASSY (1CD−FTV)(From September, 2003)
COMPONENTS
