0-160-16
RECOMMENDED LUBRICANT QUANTITY & TYPES
Note:
Since the hydraulic oil volume varies with the mast specification, be sure to check finally with the level
gauge.
Description Application Quantity l (US gal) Classification Type
Engine Gasoline 4Y 4.0 (1.06)
API
SH, SJ, SL, SM
Motor oil
SAE30
SAE10W-30
Transmission T/C 9.5 ~ 10.7 (2.51 ~ 2.82) ATF
GM Dexron
®
II
Differential All models 4.8 (1.27)
API
GL-4
Hypoid gear oil
SAE85W-90
Hydraulic oil
(V mast, max. lifting height
3300 mm (131 in))
1 ton series 30 (7.9)
ISO
VG32
Hydraulic oil
Fuel tank All models 27 (7.1) —— ————
Brake All models
Proper quantity
Reservoir Tank
0.2 (0.05)
——
SAE J-1703
DOT-3
Chassis parts All models Proper quantity ——
• MP grease
• Molybdenum
disulfide grease
Coolant
(excluding reservoir tank)
4Y LLC
• LLC 30-50% mixture
(for winter or
allseason)
• Coolant with
rustinhibitor
(for spring, summer
and autumn)
Coolant (Reservoir Tank) All models
0.47 (0.124)
(at Full level)
↑↑
To Next Page
