185
4-4. Refueling
COASTER_GW-E
4
Driving
Open the fuel tank cap.
(P. 183)
Open the door to the right side
of the fuel filler door. Turn the
fuel extraction valve (red) clock-
wise to close it. Turn the
refueling valve (gray)
counterclockwise to open it for
refueling.
Connect an LPG refueling gun to the refueling plug.
As the maximum refueling quantity may change depending on the ambient
temperature and LPG composition, it is necessary to read the fuel gauge
while refueling. For reference, when the ambient temperature is 15ºC
(59ºF), the cylinder can be filled up to 85% of its capacity. (P. 186)
Turn the refueling valve (gray) clockwise to close it. Turn the fuel
extraction valve (red) counterclockwise to open it. Then close the
door to the right side of the fuel filler door.
Remove the LPG refueling gun. Set the cap of the refueling plug
and turn it clockwise to close it.
Refueling (LPG engine)
1
2
3
4
5
COASTER_OM_General_OM36742W
