2. Instrument cluster
COASTER_GW-E
2
Instrument cluster
Optitron type
Engine coolant temperature gauge
Displays the engine coolant temperature.
Speedometer
Displays the vehicle speed.
Fuel gauge
Displays the quantity of fuel remaining in the tank.
Trip information/meter light control button
P. 6 6
Trip information/meter light control display (if equipped)
P. 6 6
Tachometer (if equipped)
Displays the engine speed in revolutions per minute.
Outside temperature display (if equipped)
The temperature range that can be displayed is from -40C (-40F) to 50C
(122F).
When the outside temperature drops below 3C (37F), comes on after
flashing 10 times.
Multi-information display (if equipped)
Presents the driver with a variety of driving-related data (P. 69)
Drive information button (if equipped)
P. 6 9
DPF deposition monitor (if equipped)
P. 163
1
2
3
4
5
6
7
8
9
COASTER_OM_General_OM36742W
