TOYOTA VENZA 2021 - DASHCAM (Digital Video Recorder)
Procedure
NOTE: Do not block access to the indicated
clip hole or else roof console may not attach
correctly.
(i) Clip off extra wire tie length.
11. Reassemble the console
(a) Reconnect roof console connector.
(b) Reinstall roof console (Fig. 11-1).
(1) Engage front hooks of the roof
console into the headliner opening.
Tilt up and push upward to engage
the clips into the roof.
NOTE: Make sure to align clip holes before
pushing up to avoid damage to clips.
(c) Place the Quick Start Guide in the Glove
Box.
12. Reconnect Battery.
(a) Reconnect the negative battery cable
(Fig. 12-1).
Torque: 5.4 N•m (48 in•lbsf)
CAUTION: Do not touch the positive terminal
with any tool.
13. Reinstall Battery Cover and Remove
Protective Covering
(a) Reinstall battery service hole cover in step 1c
(b) Remove and discard vehicle protective
covering
10mm socket & torque wrench
Fig. 11-1
To Next Page
