Toyota VENZA PT949-08210 User Manual

TOYOTA VENZA 2021 - DASHCAM (Digital Video Recorder)
Procedure
Page 4 of 11 pages
Issue: D 4/14/2021
DIO
(b) Once fully detached, disconnect roof console
(Fig. 4-2).
5. Remove the TSS Cover
(a) Rotate the mirror down to gain adequate
clearance (Fig. 5-1).
(b) Remove the 2-piece mirror cover plate (Fig.
5-2).
(1) Pull down on the upper edge of the
plate to disengage the clips (Fig. 5-3
circled in red) This can be done with
a hooked panel tool.
(2) Alternatively, you reach into and the
upper edge of the cover with your
fingers.
Fig. 4-2
Fig. 5-1
Fig. 5-2
