Toyota VENZA PT949-08210 User Manual

TOYOTA VENZA 2021 - DASHCAM (Digital Video Recorder)
Procedure
Page 8 of 11 pages
Issue: D 4/14/2021
DIO
9. Hook harness protector under headliner
(a) Use one hand to slightly pull headliner down
and use the other hand to extend the harness
protector. Hook the protector under the
headliner (Fig. 9-1 and Fig. 9-2).
10. Route/Bundle Wire Harness
(a) Pull the white Y-Harness connector through
the headliner opening and connect to the
white Dash Cam connector (Fig. 10-1).
Fig. 9-1
Fig. 9-2
Fig. 10-1
