TOYOTA VENZA 2021 - DASHCAM (Digital Video Recorder)
Procedure
(a) From the driver side of the windshield, locate
the notch in the front edge of the headliner.
(b) Route the Dash Cam pigtail through the
notch and into the headliner (Fig. 8-1).
(c) Hook the Dashcam wire extension cover
hooks into the headliner (Fig. 8-2).
(d) Swing Dashcam unit onto the base plate.
Gaps all around the dashcam unit and
windshield should be even (Fig. 8-2).
(e) Press down on dashcam unit to secure to base
plate. Dashcam unit will move slightly as it
fits to its final position (Fig. 8-2).
NOTE: Do not remove the hang tag that is
present with the Dash Cam. Keep hang tag
in front of the Dash Cam, between the
windshield and the Dash Cam (Fig. 8-3).
HANG TAG
Do NOT Remove
To Next Page
