TOYOTA VENZA 2021 - DASHCAM (Digital Video Recorder)
Procedure
(3) Slide the cover up and back to
disengage the lower hooks (Fig. 5-3
circled in yellow).
(c) Remove the TSS cover by sliding the cover
down (Fig. 5-4) from the TSS cover base.
6. Install the Y-Harness
(a) Disconnect the mirror from the vehicle wire
harness by pushing in on the release tab (Fig.
6-1).
(b) Install the Y-harness between the mirror
connector and the vehicle mirror wire
harness connector.
(1) Pull the whole harness into headliner.
To Next Page
