TP-Link Tapo C320WS User Manual

13
Install Waterproof Items
When the camera is installed outdoors, please install waterproof items to waterproof your camera. Make sure each part is securely attached and the
water-proong rings are ush to keep out water.
Follow the steps below to install waterproof items, or follow the installation video at
https://www.tp-link.com/support/setup-video/.
Install Waterproof Cable Attachments
Install the waterproof cable attachments for the network interface when the camera is installed outdoors.
Fix Nut
Waterproof
Ring
O-ring
Network
Interface
Waterproof
Jacket
1. Route the network cable through the following components in order: x nut, waterproof ring, and then the waterproof jacket.
2. Insert the waterproof ring into the waterproof jacket.
3. Fix the O-ring to the network interface of the camera and connect the network cables.
4. Attach the network interface with the waterproof jacket, then twist to lock. Rotate the x nut to secure it to the waterproof jacket.
Done! The network interface is now waterproof.
Install Waterproof Seal for Power Connectors
Install the waterproof seal for the power connectors when the camera is installed outdoors.
Male Power Connector Waterproof Seal Female Power Connector

TP-Link Tapo C320WS Specifications

General

Type	IP security camera
Alarm input/output	Yes
Placement supported	Indoor & outdoor
Connectivity technology	Wireless
Bluetooth	-
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Wi-Fi data rate (max)	150 Mbit/s
Total megapixels	4 MP
Maximum resolution	2160 x 1440 pixels
Video formats supported	H.264
Sustainability certificates	CE
Mobile operating systems supported	Android 10, Android 10.0, Android 4.4, Android 5.1, Android 6.0, Android 7.0, Android 7.1, Android 7.1.2, Android 8.0, Android 9.0, iOS 10.0, iOS 11.0, iOS 11.4, iOS 12, iOS 13, iOS 14.5, iOS 9.0, iOS 9.1, iOS 9.2, iOS 9.3
LED type	IR
Infra-red wavelength	850 nm
Night vision distance	30 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-20 - 45 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Form factor	Bullet
Mounting type	Wall
Product color	White
LED indicators	System
AC input voltage	100 - 240 V
DC output current	0.6 A
DC output voltage	9
Power source type	AC, DC
AC input frequency	50 - 60 Hz
Number of sensors	1
Optical sensor size	1/3 \
Fixed focal length	3.18 mm
Audio system	2-way
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash)
Harmonized System (HS) code	85258900

Weight and Dimensions

Depth	103.4 mm
Width	142.3 mm
Height	64.3 mm
Package depth	201.5 mm
Package width	189.5 mm
Package height	92.5 mm
Package weight	490 g
