TP-Link Tapo C320WS User Manual

3
Appearance
MicroSD Card Slot
Hold for 5 seconds to
reset the camera
Speaker
RESET
MIC
DC Power Connector
Used to connect to a 9V DC
power adapter
Ethernet Port
Used to connect to a
network device
System LED
Insert a microSD card
for local recording
IR LED
White Light LED
Front Panel Bottom Panel

TP-Link Tapo C320WS Specifications

General

Type	IP security camera
Alarm input/output	Yes
Placement supported	Indoor & outdoor
Connectivity technology	Wireless
Bluetooth	-
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Wi-Fi data rate (max)	150 Mbit/s
Total megapixels	4 MP
Maximum resolution	2160 x 1440 pixels
Video formats supported	H.264
Sustainability certificates	CE
Mobile operating systems supported	Android 10, Android 10.0, Android 4.4, Android 5.1, Android 6.0, Android 7.0, Android 7.1, Android 7.1.2, Android 8.0, Android 9.0, iOS 10.0, iOS 11.0, iOS 11.4, iOS 12, iOS 13, iOS 14.5, iOS 9.0, iOS 9.1, iOS 9.2, iOS 9.3
LED type	IR
Infra-red wavelength	850 nm
Night vision distance	30 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-20 - 45 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Form factor	Bullet
Mounting type	Wall
Product color	White
LED indicators	System
AC input voltage	100 - 240 V
DC output current	0.6 A
DC output voltage	9
Power source type	AC, DC
AC input frequency	50 - 60 Hz
Number of sensors	1
Optical sensor size	1/3 \
Fixed focal length	3.18 mm
Audio system	2-way
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash)
Harmonized System (HS) code	85258900

Weight and Dimensions

Depth	103.4 mm
Width	142.3 mm
Height	64.3 mm
Package depth	201.5 mm
Package width	189.5 mm
Package height	92.5 mm
Package weight	490 g
