TP-Link Tapo C320WS User Manual

7
Set Up Using Amazon Frustration-Free Setup
What is Amazon Frustration-Free Setup?
Amazon Frustration-Free Setup can help connect and set up Tapo smart devices in fewer steps, without having to remember and re-enter your Wi-Fi
password on each device.
To use this feature, conrm the following:
● The new Tapo device supports Amazon FFS.
● You have an Amazon FFS enabled Alexa device or router.
● You have saved your Wi-Fi information to Amazon by using Alexa echo.
● Your Tapo device and router are on the same network as your Alexa echo.
LED Indications during Amazon Frustration-Free Setup
LED Status
Blinking amber and green Ready for setup
Blinking amber FFS setup in progress
Solid green Working properly
If the LED does not turn solid green after a long time, you can try to add the Tapo device manually. (Press the Reset button on your Tapo device once.
Then open the Tapo app, tap the + button on the page, select your device model, and follow the app instructions. )

TP-Link Tapo C320WS Specifications

General

Type	IP security camera
Alarm input/output	Yes
Placement supported	Indoor & outdoor
Connectivity technology	Wireless
Bluetooth	-
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Wi-Fi data rate (max)	150 Mbit/s
Total megapixels	4 MP
Maximum resolution	2160 x 1440 pixels
Video formats supported	H.264
Sustainability certificates	CE
Mobile operating systems supported	Android 10, Android 10.0, Android 4.4, Android 5.1, Android 6.0, Android 7.0, Android 7.1, Android 7.1.2, Android 8.0, Android 9.0, iOS 10.0, iOS 11.0, iOS 11.4, iOS 12, iOS 13, iOS 14.5, iOS 9.0, iOS 9.1, iOS 9.2, iOS 9.3
LED type	IR
Infra-red wavelength	850 nm
Night vision distance	30 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-20 - 45 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Form factor	Bullet
Mounting type	Wall
Product color	White
LED indicators	System
AC input voltage	100 - 240 V
DC output current	0.6 A
DC output voltage	9
Power source type	AC, DC
AC input frequency	50 - 60 Hz
Number of sensors	1
Optical sensor size	1/3 \
Fixed focal length	3.18 mm
Audio system	2-way
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash)
Harmonized System (HS) code	85258900

Weight and Dimensions

Depth	103.4 mm
Width	142.3 mm
Height	64.3 mm
Package depth	201.5 mm
Package width	189.5 mm
Package height	92.5 mm
Package weight	490 g
