Sound power levels
Discharge
Measurement conditions:
Measurements taken in a room adjacent to the room containing the FWD, at the outlet of the rectangular duct (1.5 m
long) fixed to its discharge opening.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 55 50 42 37 37 31 30 46
FWD 08 2 57 54 47 40 30 38 40 50
3 58 57 50 42 32 40 43 53
1 57 51 45 42 34 33 28 48
FWD 10 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 57 51 45 42 34 33 28 48
FWD 12 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 56 62 50 48 39 38 36 56
FWD 14 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
1 57 63 51 49 40 39 37 57
FWD 20 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
Intake
Measurement conditions:
Measurements taken at the horizontal air intake.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 56 55 55 53 46 45 42 57
FWD 08 2 63 62 60 60 53 53 53 64
3 66 65 63 62 56 55 57 67
1 62 58 55 58 51 48 44 61
FWD 10 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 62 58 55 58 51 48 44 61
FWD 12 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 66 65 65 65 57 50 46 68
FWD 14 2 73 72 69 71 64 59 57 74
3 78 76 73 75 69 64 63 78
1 68 72 64 64 56 52 50 69
FWD 20 2 76 76 68 71 65 61 61 75
3 78 79 71 74 69 66 66 78
General Data
Table 1 - CGAX 015-035 General Data
CGAX
015
SE-SN
CGAX
017
SE-SN
CGAX
020
SE-SN
CGAX
023
SE-SN
CGAX
026
SE-SN
CGAX
030
SE-SN
CGAX
035
SE-SN
Net Cooling Capacity R410A (1) (kW) 44.8 50.7 59.9 66.8 75.7 83.6 100.0
Total Power input in cooling R410A (1) (kW) 14.8 17.4 19.0 22.2 25.8 29.3 35.3
Net cooling capacity R454B (1) (kW) 40.9 48.4 56.4 63.7 74.6 81.8 100.4
Total Power input in cooling R454B (1) (kW) 14.6 17.3 18.1 21.1 24.5 28 33.6
Unit electrical data (2) (3) (4)
Short Circuit Unit Capacity (9) (kA) 12 12 12 12 12 12 15
Power Cable Cross Section (max) mm² 35 35 35 35 35 35 150
Disconnect switch size (A) 80 80 100 100 100 100 250
Digit 12=1 and Digit 15=A
Maximum Power input (kW) 19.4 22.1 25.8 29.5 33.3 37.0 44.2
Unit rated amps (A) 33.8 38.5 45.4 50.5 55.6 64.0 76.5
Unit start up amps (w/o soft starter - Digit 26=A) (4) (A) 116.3 160.3 167.2 183.2 188.3 189.5 198.3
Unit start up amps (with soft starter - Digit 26=B) (4) 77.1 103.5 110.4 120.0 125.1 127.5 141.5
Power factor 0.845 0.846 0.836 0.861 0.880 0.847 0.846
Digit 12=1 and Digit 15=C
Maximum Power input (kW) 20.4 23.2 26.8 30.6 34.3 38.1 46.4
Unit rated amps (A) 34.5 39.2 46.2 51.3 56.4 64.8 78.1
Unit start up amps (w/o soft starter - Digit 26=A) (4) (A) 117.0 161.0 168.0 184.0 189.1 190.3 199.9
Unit start up amps (with soft starter - Digit 26=B) (4) 77.8 104.2 111.2 120.8 125.9 128.3 143.1
Power factor 0.868 0.866 0.854 0.875 0.892 0.859 0.866
Compressor
Compressor Number per Circuit # 2 2 2 2 2 2 2
Type Scroll Scroll Scroll Scroll Scroll Scroll Scroll
Model Circuit1 / Circuit 2 7.5+7.5 7.5+10 10+10 10+13 13+13 15+15
7.5+10 /
7.5+10
Max Compr Power input Circuit 1/Circuit 2 kW 9.2 + 9.2 9.2+ 12 12 + 12 12 + 15.7 15.7 + 15.7 17.61 + 17.6
9.2 + 12 /
9.2 + 12
Rated Amps Circuit1 / Circuit 2 (4) (A) 15.5 + 15.5 15.5 + 20.2 20.2 + 20.2 20.2 + 25.3 25.3 + 25.3 29.5 + 29.5
15.5 + 20.2 /
15.5 + 20.2
Locked Rotor Amps Circuit1 / Circuit 2 (4) (A) 98 + 98 98 + 142 142 + 142 142 + 158 158 + 158 155 + 155
98 + 142 /
98 + 142
Motor RPM (rpm) 2900 2900 2900 2900 2900 2900 2900
Oil sump heater Circuit1 / Circuit 2 (W) 0.17 / 0 0.17 / 0 0.17 / 0 0.17 / 0 0.17 / 0 0.17 / 0 0.17 / 0.17
Evaporator
Quantity # 1 1 1 1 1 1 1
Type Stainless steel Copper Brazed plate Heat exchanger
Evaporator model P80x66 P80x92 P80x92 P80x92 P120Tx76 P120Tx76 DP300x82
Evaporator Water Content volume (l) 3.8 5.3 5.3 5.3 9.2 9.2 8.5
Nominal water connection size
(Grooved coupling) - Without HYM
(in) -
(mm)
2" - 60.3 2" - 60.3 2" - 60.3 2" - 60.3 2" - 60.3 2" - 60.3 3" OD - 76.1
Nominal water connection size
(Grooved coupling) - With HYM
(in) -
(mm)
2" - 60.3 2" - 60.3 2" - 60.3 2" - 60.3 2" - 60.3 2" - 60.3 3" OD - 76.1
Hydraulic Module Components
Single pump - Standard head pressure option
Max available Head Pressure (kPa) 96 100 86 113 120 110 111
Motor Power (kW) 1.20 1.20 1.20 1.50 1.50 1.50 1.50
Rated Amps (A) 2.44 2.44 2.44 3.50 3.50 3.50 3.50
Single pump - High head pressure option
Max available Head Pressure (kPa) 170 174 162 152 161 152 151
Motor Power (kW) 2.30 2.30 2.30 2.30 2.30 2.30 3.00
Rated Amps (A) 5.03 5.03 5.03 5.03 5.03 5.03 6.23
Twin pump - Standard head pressure option
Max available Head Pressure (kPa) 96 100 86 113 120 110 111
Motor Power (kW) 1.20 1.20 1.20 1.50 1.50 1.50 1.50
Rated Amps (A) 2.44 2.44 2.44 3.50 3.50 3.50 3.50
Twin pump - High head pressure option
Max available Head Pressure (kPa) 170 174 162 152 161 152 198
Motor Power
(kW) 2.30 2.30 2.30 2.30 2.30 2.30 3.00
Rated Amps (A) 5.03 5.03 5.03 5.03 5.03 5.03 6.23
Expansion Tank Volume (l) 25 25 25 25 25 25 35
Max User water loop Volume for factory mounted
expansion tank (1)
(l) 1450 1450 1450 1450 1450 1450 2000
OptionnalwaterBuertankvolume (l) 324 324 324 324 324 324 444
Antifreeze Heater without pump package (W) 120 120 120 120 120 120 120
Antifreeze Heater with pump package (W) 280 280 280 280 280 280 280
Condenser
Type Full aluminum Micro channel heat exchanger
Quantity of coil # 1 1 1 1 1 1 2
Face area per circuit (m²) 2.23 2.23 2.96 2.96 2.96 2.96 2.96
